OnePlus 5 specs: Snapdragon 835, 3300mAh battery, optional 8GB RAM and 128GB storage

OnePlus has always played the spec game, and with the OnePlus 5, it's offering just about everything inside that people are asking for. That starts with the top-end Snapdragon 835 processor and continues to an optional 8GB of RAM and 128GB of storage. The 3,300mAh battery is right around the industry average, and you're missing a couple things like waterproofing and an SD card slot, but on the whole OnePlus set another high bar for the specs you can fit in a single phone and not have it cost a fortune.

Perhaps most impressive of all, from a smartphone nerd standpoint, is that OnePlus has just one model for the entire world — including radio bands to be used in dozens of countries. Combine that with its dual SIM capability and you have a true world phone.

CategorySpec
Operating SystemAndroid 7.1.1 Nougat
Display5.5-inch AMOLED, 1920x1080 (401 ppi)
Gorilla Glass 5
ProcessorQualcomm Snapdragon 835 octa-core 2.45GHz
GPUAdreno 540
RAM6/8GB LPDDR4X
Storage64/128GB UFS 2.1
ExpandableNo
Battery3300mAh
ChargingUSB-C
Dash Charge
Water resistanceNo
Rear Camera 116MP (IMX398), f/1.7, 1.12-micron pixels, EIS
Dual LED flash, 4K 30 fps / 720p 120 fps video
Rear Camera 220MP (IMX350), f/2.6, 1-micron pixels
Front Camera16MP (IMX371), f/2.0, 1-micron pixels, EIS
1080p 30 fps video
ConnectivityLTE 3xCA, 256QAM, Cat 12
Wi-Fi 802.11 ac, dual band, 2x2 MIMO
Bluetooth 5.0, aptX HD
GPS, GLONASS, BeiDou, NFC
USB 2.0, USB OTG
SecurityOne-touch fingerprint sensor
SIMDual Nano SIM
NetworkFDD-LTE: Band 1/2/3/4/5/7/8/12/17/18/19/20/25/26/28/29/30/66
TDD-LTE: Band 38/39/40/41
HSPA: Band 1/2/4/5/8
TD-SCDMA: Band 34/39
GSM 850/900/1800/1900 MHz
CDMA: BC0
Dimensions154.2 x 74.1 x 7.25 mm
153 g
ColorsSlate grey, Midnight black
